Cutting Tools Designed Around Edgecam Waveform

Estimated reading time 3 minutes

Edgecam’s “Inspire” productivity event in partnership with Mazak, Sandvik Coromant and Iscar Tools has been described as “industry leaders showing innovative technology.” And  delegates  learned  that  tools  are now being designed around the CAD/CAM software’s Waveform milling strategy.

Edgecam UGM and Productivity Day1Live machining demonstrations show cased Waveform high speed roughing in both milling and turning environments, which increases productivity and significantly reduces costs. It maintains a constant tool cutting load by ensuring a consistent tool engagement with the material.

Edgecam’s Strategic Partnership Manager Wesley Tonks says: “End-users are typically benefitting from increased material removal rates of 80 per cent, on mills and 300 per cent in turning environments.”

Held at Mazak UK in Worcester, the event included two demonstrations, the first featuring a Great British Sports Cars brake caliper. The part was machined on a Mazak VERTICAL CENTER SMART 430A, using tools from Sandvik Coromant. Amongst the machining highlights: Waveform face milling and rough profiling; along with flow surface, constant cusp, profiling and parallel lace finishing cycles. Soft jaws were created using Boolean Difference in Part Modeler.

The part was inspected with a ROMER Absolute  Arm, from Vero’s parent company. Hexagon Manufacturing Intelligence. In a separate presentation, Hexagon Product Line Specialist Jamie Barnett detailed the technology behind the arm, which utilises PC-DMIS laser scanning to produce a point cloud, capturing data to generate an stl file.

The second demonstration showed the Waveform high speed turning cycle on a Mazak INTEGREX i-400, with Iscar cutting tools. Delegates were particularly impressed with the new Ramp Strategy in the rough turn cycle, rotary machining, and 5-axis finishing.

Wesley Tonks says: “Following machine tooling presentations from Iscar Product Managers Andy Hayward andEdgecam UGM and Productivity Day3 John Williams, and Sandvik Coromant’s Ben Lodge, it became clear that tools are now being designed around the Waveform milling strategy.”

And James Rhys Davies, Sandvik Coromant’s Machine Investment Manager, says events like Edgecam’s Inspire event are important in showing delegates why specific tools and strategies are deployed. “Manufacturers benefit from machine tool builders, cutting tool and CAD/CAM companies working in partnership, as it provides a true cohesive approach which keeps production costs down.”

A point echoed by Ross Thatcher, Manufacturing Engineer at Horstman Defence, who says the Inspire event showed how the three disciplines working together provide an overall manufacturing solution. He was also particularly interested to learn how to extend Horstman’s Waveform Roughing capabilities. “We currently only use Waveform roughing for milling, so are now looking to see how it can cut down cycle times for our turning operations, too.”

And delegate Richard Blake, Business Development Manager at GW Martin, says Edgecam 2016 R1 is a vital aspect of their plans for next year as they expand the business.“Expansion means we need to get more complex components produced quicker, and Edgecam will play a major role in setting up parts and producing the first off as quickly as possible. Investing in Edgecam 2016 R1 will speed up our front end programming, meaning faster times for getting new parts into production.”

Wesley Tonks concludes: “The Inspire event was all about industry leaders demonstrating innovative technology.”
